| Sipariş KoduOrdering Code | Stok KoduItem No | Kesici Uç Markası | Şaft Tipi | Kesici Uç Tipi | Kesici Uç Ölçüsü | ZEFP | DCmm | LHmm | LFmm | DCONmm | APMXmm |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AHFM-LS02-D12-C12-L120-Z02-H | M.06.09.29.02 | TNGLY | Silindirik | LSMT | 0202R2-MM | 2 | 12 | 20 | 120 | 12 | 0.5 |
| AHFM-LS02-D10-C10-L120-Z02-H | M.06.09.29.01 | TNGLY | Silindirik | LSMT | 0202R2-MM | 2 | 10 | 70 | 120 | 10 | 0.5 |
| AHFM-LO03-D16-C16-L220-Z02-H | M.06.09.22.21 | KYCR | Silindirik | LOGU | 0303.. | 2 | 16 | 120 | 220 | 16 | 1 |
| AHFM-LN0303-D28-C25-L180-Z03 | M.06.09.18.12 | TNGLY | Silindirik | LNMU | 0303.. | 3 | 28 | 30 | 180 | 25 | 1 |
| AHFM-LN0303-D17-C16-L150-Z02-H | M.06.09.18.13 | TNGLY | Silindirik | LNMU | 0303.. | 2 | 17 | 30 | 150 | 16 | 1 |
| AHFM-BL0603-D26-C25-L150-Z04 | M.06.09.05.27 | TGTC | Silindirik | BLMP | 0603.. | 4 | 26 | 35 | 150 | 25 | 1 |
| AHFM-SP0735-D20-C20-L160-Z03-H | M.06.09.33.01.03 | MTSBH | Silindirik | SPMX | 073505 | 3 | 20 | 30 | 160 | 20 | 1.2 |
| AHFM-SP0735-D16-C16-L160-Z02-H | M.06.09.33.01.01 | MTSBH | Silindirik | SPMX | 073505 | 2 | 16 | 30 | 160 | 16 | 1.2 |
| AHFM-SO0803-D35-W32-L160-Z04 | M.06.09.16.05 | KPTK | Veldon | SOMW | 0803.. | 4 | 35 | 50 | 160 | 32 | 1 |
| AHFM-XN06T3-D20-W20-L80-Z03-H | M.06.09.38.01.03 | PLBT | Veldon | XNKU | 06T3.. | 3 | 20 | 30 | 80 | 20 | 1.25 |
| AHFM-XN06T3-D20-W20-L110-Z03-H | M.06.09.38.01.04 | PLBT | Veldon | XNKU | 06T3.. | 3 | 20 | 60 | 110 | 20 | 1.25 |
| AHFM-BL0603-D30-C25-L150-Z05 | M.06.09.05.29 | TGTC | Silindirik | BLMP | 0603.. | 5 | 30 | 40 | 150 | 25 | 1 |
| AHFM-YO0602-D10-C10-L120-Z02-H | M.06.09.19.04 | DJT | Silindirik | YOHW | 0602.. | 2 | 10 | 60 | 120 | 10 | 0.3 |
| AHFM-SP0735-D17-C16-L160-Z02-H | M.06.09.33.01.02 | MTSBH | Silindirik | SPMX | 073505 | 2 | 17 | 30 | 160 | 16 | 1.2 |
| AHFM-YO0602-D12-C11-L120-Z02-H | M.06.09.19.11 | DJT | Silindirik | YOHW | 0602.. | 2 | 12 | 15 | 120 | 11 | 0.3 |
| AHFM-YO0602-D10-C10-L120-Z02-H-F | M.06.09.17.04 | DJT | Silindirik | YOHW | 0602.. | 2 | 10 | 60 | 120 | 10 | 0.3 |
| AHFM-SP0735-D21-C20-L160-Z03-H | M.06.09.33.01.04 | MTSBH | Silindirik | SPMX | 073505 | 3 | 21 | 30 | 160 | 20 | 1.2 |
| AHFM-YO0602-D12-C12-L080-Z03-F | M.06.09.17.09 | DJT | Silindirik | YOHW | 0602.. | 3 | 12 | 20 | 80 | 12 | 0.3 |
ZEFP = Kesici Uç Sayısı · DC = Kesme Çapı · LH = Boyun Uzunluğu · LF = Fonksiyonel Uzunluk · DCON = Bağlantı Çapı · APMX = Maksimum Kesme Derinliği
Yedek Parçalar: 3008-M2.5X6 TORX VİDA · 82-T08 TORX ANAHTARI · 3006-M1.8X4 TORX VİDA · 82-T06 TORX ANAHTARI · 3008-M2.5X5 TORX VİDA · 4010-M3X6 TORX VİDA · 82-T10 TORX ANAHTARI · 4010-M3X8 TORX VİDA · AACN-3-0008 CNMG 25 ALTLIK · 3007-M2.2X4.6 TORX VİDA · 3010-M3.5X9 TORX VİDA · 4015-M4X11 TORX VİDA · 80-T15 TORK ANAHTARI · 3015-M3.5X9 TORX VİDA · 3108-M3X6 TORX VİDA · 4008-M2.5X6 TORX VİDA
