| Sipariş KoduOrdering Code | Stok KoduItem No | İçten Soğutmalı | Kesici Uç Markası | Kesici Uç Tipi | TDZ | Kesici Uç Ölçüsü | ZEFP | DCmm | LFmm | DCONmm | APMXmm | DCSFMSmm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AHFM-BN10T3-D16-M08-L25-Z02-H | M.06.14.22.01 | Evet | PRMT | BNGX | M08 | 10T3.. | 2 | 16 | 25 | 8.5 | 1 | 14.75 |
| AHFM-WN09T3-D35-M16-L40-Z04-H | M.06.14.08.03 | Evet | KRLY | WNMX | M16 | 09T3.. | 4 | 35 | 40 | 17 | 1.5 | 29 |
| AHFM-SO0803P-D42-M16-L35-Z05-H | M.06.14.09.06 | Evet | PLBT | SOEW | M16 | 0803.. | 5 | 42 | 35 | 17 | 1 | 29 |
| AHFM-SO0803P-D32-M16-L35-Z04-H | M.06.14.09.05 | Evet | PLBT | SOEW | M16 | 0803.. | 4 | 32 | 35 | 17 | 1 | 29 |
| AHFM-SO0803-D40-M16-L43-Z05-H | M.06.14.09.07 | Evet | KPTK | SOMW | M16 | 0803.. | 5 | 40 | 43 | 17 | 1 | 29 |
| AHFM-BL0603-D21-M10-L35-Z03-H | M.06.14.07.07 | Evet | TGTC | BLMP | M10 | 0603.. | 3 | 21 | 35 | 10.5 | 1 | 18 |
| AHFM-BL0603-D17-M08-L35-Z02-H | M.06.14.07.08 | Evet | TGTC | BLMP | M08 | 0603.. | 2 | 17 | 35 | 8.5 | 1 | 14.75 |
| AHFM-XD0904WD-D33-M16-L43-Z04-H | M.06.14.11.03 | Evet | WDA | XDPT | M16 | 0904.. | 4 | 33 | 43 | 17 | 1.5 | 29 |
| AHFM-XD0904WD-D26-M12-L35-Z03-H | M.06.14.11.02 | Evet | WDA | XDPT | M12 | 0904.. | 3 | 26 | 35 | 12.5 | 1.5 | 21 |
| AHFM-SO1004-D35-M16-L40-Z03-H | M.06.14.16.07 | Evet | KYCR | SOMT | M16 | 1004.. | 3 | 35 | 40 | 17 | 1.5 | 29 |
| AHFM-SP0945-D42-M16-L43-Z05-H | M.06.14.23.02.03 | Evet | MTSBH | SPMX | M16 | 094506 | 5 | 42 | 43 | 17 | 1.4 | 29 |
| AHFM-SP0735-D25-M12-L35-Z04-H | M.06.14.23.01.04 | Evet | MTSBH | SPMX | M12 | 073505 | 4 | 25 | 35 | 12.5 | 1.2 | 21 |
| AHFM-SP0735-D20-M10-L30-Z03-H | M.06.14.23.01.03 | Evet | MTSBH | SPMX | M10 | 073505 | 3 | 20 | 30 | 10.5 | 1.2 | 18 |
| AHFM-SP0735-D16-M08-L23-Z02-H | M.06.14.23.01.01 | Evet | MTSBH | SPMX | M08 | 073505 | 2 | 16 | 23 | 8.5 | 1.2 | 14.75 |
| AHFM-SP0945-D35-M16-L43-Z04-H | M.06.14.23.02.02 | Evet | MTSBH | SPMX | M16 | 094506 | 4 | 35 | 43 | 17 | 1.4 | 29 |
| AHFM-SP0945-D32-M16-L43-Z04-H | M.06.14.23.02.01 | Evet | MTSBH | SPMX | M16 | 094506 | 4 | 32 | 43 | 17 | 1.4 | 29 |
TDZ = Diş Çapı Boyutu · ZEFP = Kesici Uç Sayısı · DC = Kesme Çapı · LF = Fonksiyonel Uzunluk · DCON = Bağlantı Çapı · APMX = Maksimum Kesme Derinliği · DCSFMS = Makine Tarafı Temas Yüzeyi Çapı
Yedek Parçalar: 3008-M2.5X6 TORX VİDA · 82-T08 TORX ANAHTARI · 3010-M3.5X9 TORX VİDA · 82-T10 TORX ANAHTARI · 3006-M1.8X4 TORX VİDA · 82-T06 TORX ANAHTARI · 3008-M2.5X5 TORX VİDA · 4015-M4X11 TORX VİDA · 80-T15 TORK ANAHTARI · 4010-M3X8 TORX VİDA · 4010-M3X6 TORX VİDA · AACN-3-0008 CNMG 25 ALTLIK · 3007-M2.2X4.6 TORX VİDA · 3015-M3.5X9 TORX VİDA · 4015-M4X9 TORX VİDA · 4015-M3.5X9 TORX VİDA · 3108-M3X6 TORX VİDA
