| Sipariş KoduOrdering Code | Stok KoduItem No | Kesici Uç Markası | Kesici Uç Ölçüsü | Kesici Uç Tipi | KAPR° | DCXmm | ZEFP | DCmm | LHmm | LFmm | DCONmm | APMXmm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ACM72-TC16-D14X42-W20-L100-Z03 | M.06.05.01.25 | ISO | 16T304 | TCMT | 72 | 42 | 3 | 14 | 40 | 100 | 20 | 4.6 |
| ACM45-TC16-D5X26-W16-L100-Z01 | M.06.05.01.95 | ISO | 16T304 | TCMT | 45 | 26 | 1 | 5 | 30 | 100 | 16 | 10.8 |
| ACM45-TC16-D30X51-W20-L100-Z02 | M.06.05.01.91 | ISO | 16T304 | TCMT | 45 | 51 | 2 | 30 | 40 | 100 | 20 | 10.8 |
| ACM45-TC16-D20X41-W20-L100-Z02 | M.06.05.01.90 | ISO | 16T304 | TCMT | 45 | 41 | 2 | 20 | 40 | 100 | 20 | 10.8 |
| ACM45-TC16-D18X39-W20-L100-Z02 | M.06.05.01.94 | ISO | 16T304 | TCMT | 45 | 39 | 2 | 18 | 40 | 100 | 20 | 10.8 |
| ACM45-TC16-D18X39-W16-L100-Z02 | M.06.05.01.02 | ISO | 16T304 | TCMT | 45 | 39 | 2 | 18 | 40 | 100 | 16 | 10.8 |
| ACM45-TC16-D10X31-W20-L100-Z02 | M.06.05.01.96 | ISO | 16T304 | TCMT | 45 | 31 | 2 | 10 | 35 | 100 | 20 | 10.8 |
| ACM45-TC16-D10X31-W16-L100-Z02 | M.06.05.01.89 | ISO | 16T304 | TCMT | 45 | 31 | 2 | 10 | 35 | 100 | 16 | 10.8 |
| ACM45-TC09-D7X18-W16-L100-Z02 | M.06.05.01.92 | ISO | 090204 | TCMT | 45 | 18 | 2 | 7 | 25 | 100 | 16 | 5.9 |
| ACM25-TC16-D17X29-W16-L100-Z01 | M.06.05.01.01 | ISO | 16T304 | TCMT | 25 | 29 | 1 | 17 | 30 | 100 | 16 | 13.9 |
| ACM20-TC16-D17X27-W16-L100-Z01 | M.06.05.01.88 | ISO | 16T304 | TCMT | 20 | 27 | 1 | 17 | 30 | 100 | 16 | 14.4 |
| ACM20-TC16-D12X22-W16-L100-Z01 | M.06.05.01.93 | ISO | 16T304 | TCMT | 20 | 22 | 1 | 12 | 30 | 100 | 16 | 14.4 |
| ACM18.5-TC16-D21.3X30-W20-L100-Z02 | M.06.05.01.23 | ISO | 16T304 | TCMT | 18.5 | 30 | 2 | 21.3 | 30 | 100 | 20 | 13.5 |
| ACM17.5-TC16-D17X25-W16-L90-Z01 | M.06.05.01.87 | ISO | 16T304 | TCMT | 17.5 | 25 | 1 | 17 | 30 | 90 | 16 | 14.7 |
| ACM15-TC16-D17X24-W16-L90-Z01 | M.06.05.01.86 | ISO | 16T304 | TCMT | 15 | 24 | 1 | 17 | 30 | 90 | 16 | 14.9 |
| ACM10-TC16-D17X22-W16-L90-Z01 | M.06.05.01.85 | ISO | 16T304 | TCMT | 10 | 22 | 1 | 17 | 30 | 90 | 16 | 15.2 |
| ACM50-TC16-D16X39-W20-L100-Z03 | M.06.05.01.03 | ISO | 16T304 | TCMT | 50 | 39 | 3 | 16 | 40 | 100 | 20 | 9.8 |
| ACM40-TC16-D18x37-W20-L100-Z02 | M.06.05.01.04 | ISO | 16T304 | TCMT | 40 | 37 | 2 | 18 | 40 | 100 | 20 | 11.7 |
| ACM45-TC16-D14X35-W20-L100-Z02 | M.06.05.01.10 | ISO | 16T304 | TCMT | 45 | 35 | 2 | 14 | 35 | 100 | 20 | 10.8 |
| ACM45-TC11-D8X21.5-W16-L90-Z02 | M.06.05.01.06 | ISO | 110204 | TCMT | 45 | 21.5 | 2 | 8 | 20 | 90 | 16 | 6.9 |
| ACM19.5-TC16-D17X27-W16-L100-Z01 | M.06.05.01.11 | ISO | 16T304 | TCMT | 19.5 | 27 | 1 | 17 | 30 | 100 | 16 | 14.5 |
KAPR = Yan Kesme Açısı · DCX = Maksimum Kesme Çapı · ZEFP = Kesici Uç Sayısı · DC = Kesme Çapı · LH = Boyun Uzunluğu · LF = Fonksiyonel Uzunluk · DCON = Bağlantı Çapı · APMX = Maksimum Kesme Derinliği
Yedek Parçalar: 4015-M3.5X9 TORX VİDA · 80-T15 TORK ANAHTARI · 4015-M4X9 TORX VİDA · 3008-M2.5X6 TORX VİDA · 82-T08 TORX ANAHTARI · 82-T15 TORX ANAHTARI · AACN-3-0008 CNMG 25 ALTLIK · 3007-M2.2X4.6 TORX VİDA
