| Sipariş KoduOrdering Code | Stok KoduItem No | TD | Kesici Uç Ölçüsü | WFmm | HFmm | Kesici Uç İç Daire Çapımm | LFmm | Hmm | DCONmm | THLmm |
|---|---|---|---|---|---|---|---|---|---|---|
| S16G SCACR 09 | M.07.99.59 | M6x1 | 09T308 | 16.5 | 2 | 9.525 | 90 | 15 | 16 | 30 |
| S20E SCACR 09 | M.07.99.60 | M6x1 | 09T308 | 20.5 | 2 | 9.525 | 70 | 18.3 | 20 | 30 |
| S20E SCACR 12 | M.07.99.61 | M6x1 | 120408 | 20.5 | 2 | 12.70 | 70 | 18.3 | 20 | 30 |
| S20H SCACR 12 | M.07.99.62 | M6x1 | 120408 | 20.5 | 2 | 12.70 | 100 | 18.3 | 20 | 30 |
| S12H SCACR 09 | M.07.99.16 | M5x0.8 | 09T308 | 12.3 | 2 | 9.525 | 100 | 11 | 12 | 25 |
| S12D SCACR 09 | M.07.99.19 | M5x0.8 | 09T308 | 12.3 | 2 | 9.525 | 60 | 11 | 12 | 25 |
| S18E SCACR 09 | M.07.99.07 | M8x1.25 | 09T308 | 18.5 | 2 | 9.525 | 70 | 17 | 18 | 30 |
| S16H SCACR 09 | M.07.99.06 | M6x1 | 09T308 | 16.5 | 4 | 9.525 | 100 | 15 | 16 | 35 |
| S16E SCACR 09 | M.07.99.05 | M6x1 | 09T308 | 16.5 | 2 | 9.525 | 70 | 15 | 16 | 30 |
| S16C SCACR 09 | M.07.99.04 | M6x1 | 09T308 | 16.5 | 2 | 9.525 | 50 | 15 | 16 | 25 |
| S15E SCACR 09 | M.07.99.03 | M8x1.25 | 09T308 | 15.3 | 2 | 9.525 | 70 | 14 | 15 | 45 |
| S15D SCACR 09 | M.07.99.02 | M8x1.25 | 09T308 | 15.3 | 2 | 9.525 | 60 | 14 | 15 | 30 |
| S15C SCACR 09 | M.07.99.01 | M8x1.25 | 09T308 | 15.3 | 2 | 9.525 | 50 | 14 | 15 | 25 |
| S1265 SCACR 09 | M.07.99.32 | M5x0.8 | 09T308 | 12.3 | 2 | 9.525 | 65 | 11 | 12 | 25 |
| S1065 SCACR 06 | M.07.99.33 | M5x0.8 | 060204 | 10.3 | 1 | 6.35 | 65 | 9 | 10 | 25 |
| S1018 SCACR 06 | M.07.99.34 | M5x0.8 | 060204 | 9.8 | 1 | 6.35 | 18 | 9 | 10 | 8 |
| S1888 SCACR 09 | M.07.99.82 | M8x1.25 | 09T308 | 18.5 | 2 | 9.525 | 88 | 17 | 18 | 30 |
| S1868 SCACR 09 | M.07.99.81 | M8x1.25 | 09T308 | 18.5 | 2 | 9.525 | 68 | 17 | 18 | 30 |
| S18175 SCACR 09 | M.07.99.84 | M8x1.25 | 09T308 | 18.5 | 2 | 9.525 | 175 | 17 | 18 | 30 |
| S18105 SCACR 09 | M.07.99.83 | M8x1.25 | 09T308 | 18.5 | 2 | 9.525 | 105 | 17 | 18 | 30 |
| S1554 SCACR 09 | M.07.99.80 | M8x1.25 | 09T308 | 15.3 | 2 | 9.525 | 54 | 14 | 15 | 25 |
TD = Diş Çapı · WF = Fonksiyonel Genişlik · HF = Fonksiyonel Yükseklik · LF = Fonksiyonel Uzunluk · H = Şaft Yüksekliği · DCON = Bağlantı Çapı · THL = İşlevsel Diş Uzunluğu
Yedek Parçalar: 4008-M2.5X6 TORX VİDA · 82-T08 TORX ANAHTARI · 4015-M3.5X8 TORX VİDA · 80-T15 TORK ANAHTARI · 1020-M5X11 TORX VİDA · 80-T20 TORK ANAHTARI
